Discover why bigger is better with the Discovery LXE Class A diesel motorhomes by Fleetwood RV. From more power under the hood to more interior comforts and options, this coach is sure to bring you more fun and adventure!



The Cummins L9 engine provides exceptional power, and the Freightliner custom chassis ensures a smooth drive every time. The driver will also appreciate the color backup monitor, the 10.2" stereo with touchscreen navigation, and the LED OptiView instrument panel that will make navigating the road a breeze. Inside, you'll enjoy residential appliances, porcelain tile floors with front heat, residential-style furniture, plus many more luxuries. The three 15K BTU roof A/C's will keep you cool all summer long, plus there is an 8,000-watt Onan quiet diesel generator and 6V deep cycle house batteries to keep you powered up.



"More" comes standard on a Discovery LXE Class A diesel motorhome by Fleetwood RV. Choose your favorite floorplan today!

  • Discovery LXE 40G

    Discovery LXE 40G Floorplan Image

    Take a Virtual Tour

    Fleetwood Discovery LXE Class A diesel coach 40G highlights: Full-Wall Slide ... more about Discovery LXE 40G

    Specifications

    Sleeps 8
    Slides 2
    Length 41 ft 4 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Interior Color Serenity, Ridgeland, Signature, Spanish Moss
    Exterior Color Battlefield, Carezza, Everglades, Montezuma, Plantation, Redwood
    Hitch Weight 10000 lbs
    GVWR 36600 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 275/80R 22.5H
    Generator 8kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins L9
    Chassis Freightliner Custom XCM
    Horsepower 380 hp
    Fuel Capacity 100 gals
    Wheelbase 276 in
    Number Of Bunks 2
    Available Beds King
    Torque 1150 ft-lb
    Refrigerator Type Residential w/Ice and Water In Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 32"
    Number of Awnings 1
    Axle Weight Front 12600 lbs
    Axle Weight Rear 24000 lbs
    Water Heater Type Aqua Hot 400D
    AC BTU 45000 btu
    Basement Storage 157 cu. ft.
    TV Info LR LED TV, Cab TV, BR LED TV, Ext. LED TV
    Awning Info 18' Power w/LED Lighting & Motion Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 46600 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Specifications

    Sleeps 5
    Slides 3
    Length 40 ft 1 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Interior Color Serenity, Ridgeland, Signature, Spanish Moss
    Exterior Color Battlefield, Carezza, Everglades, Montezuma, Plantation, Redwood
    Hitch Weight 10000 lbs
    GVWR 36600 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 275/80R 22.5H
    Generator 8kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins L9
    Chassis Freightliner Custom XCM
    Horsepower 380 hp
    Fuel Capacity 100 gals
    Wheelbase 263 in
    Available Beds King
    Torque 1150 ft-lb
    Refrigerator Type Residential w/Ice and Water In Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 50" x 28"
    Number of Awnings 1
    Axle Weight Front 12600 lbs
    Axle Weight Rear 24000 lbs
    Water Heater Type Aqua Hot 400D
    AC BTU 45000 btu
    Basement Storage 142 cu. ft.
    TV Info LR Pop-Up LED TV, Cab TV, BR LED TV, Ext. LED TV
    Awning Info 18' Power w/LED Lighting & Motion Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 46600 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

  • Discovery LXE 36HQ

    Discovery LXE 36HQ Floorplan Image

    Take a Virtual Tour

    Fleetwood Discovery LXE Class A diesel coach 36HQ highlights: Four LED TV's ... more about Discovery LXE 36HQ

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 4
    Length 36 ft 9 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Interior Color Enclave, Ridgeland, Signature, Spanish Moss
    Exterior Color Lakefront, Flight, Riverstone, Renewal
    Hitch Weight 10000 lbs
    GVWR 36400 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 275/80R 22.5H
    Generator 8kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins ISL9
    Chassis Freightliner XCM
    Horsepower 380 hp
    Fuel Capacity 100 gals
    Wheelbase 276 in
    Available Beds King
    Torque 1150 ft-lb
    Refrigerator Type Residential w/Ice and Water In Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 34" x 33"
    Number of Awnings 1
    Axle Weight Front 12400 lbs
    Axle Weight Rear 24000 lbs
    Water Heater Type Aqua Hot 400D
    AC BTU 45000 btu
    Basement Storage 88 cu. ft.
    TV Info LR 49" LED TV, Cab 32" TV, BR 32" LED TV, Ext. LED TV
    Awning Info 18' Roof Mounted Electric w/LED Lighting & Motion Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 46400 lbs
    Shower Type Angled
    Electrical Service 50 amp

    Similar Floorplans

  • Discovery LXE 44B

    Discovery LXE 44B Floorplan Image

    Take a Virtual Tour

    Fleetwood Discovery LXE Class A diesel coach 44B highlights: Bath and a Half ... more about Discovery LXE 44B

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 9
    Slides 4
    Length 44 ft
    Ext Width 8 ft 6 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Interior Color Serenity, Ridgeland, Signature, Spanish Moss
    Exterior Color Battlefield, Carezza, Everglades, Montezuma, Plantation, Redwood
    Hitch Weight 15000 lbs
    GVWR 43600 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 275/80R 22.5H
    Generator 8kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins L9
    Chassis Freightliner Custom XCM
    Horsepower 450 hp
    Fuel Capacity 100 gals
    Wheelbase 309 in
    Number Of Bunks 2
    Available Beds King
    Torque 1250 ft-lb
    Refrigerator Type Residential w/Ice and Water In Door
    Convection Cooking Yes
    Cooktop Burners 2
    Number of Awnings 1
    Axle Weight Front 13600 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 10000 lbs
    Water Heater Type Aqua Hot 400D
    AC BTU 45000 btu
    Basement Storage 157 cu. ft.
    TV Info LR Pop-Up LED TV, Cab TV, BR LED TV, Ext. LED TV
    Awning Info 18' Power w/LED Lighting & Motion Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 58600 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Discovery LXE 44S

    Discovery LXE 44S Floorplan Image

    Take a Virtual Tour

    Fleetwood Discovery LXE Class A diesel coach 44S highlights: Four Slides ... more about Discovery LXE 44S

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 4
    Length 44 ft
    Ext Width 8 ft 6 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Interior Color Serenity, Ridgeland, Signature, Spanish Moss
    Exterior Color Battlefield, Carezza, Everglades, Montezuma, Plantation, Redwood
    Hitch Weight 15000 lbs
    GVWR 43600 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 275/80R 22.5H
    Generator 8kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins L9
    Chassis Freightliner Custom XCM
    Horsepower 450 hp
    Fuel Capacity 100 gals
    Wheelbase 309 in
    Available Beds King
    Torque 1250 ft-lb
    Refrigerator Type Residential w/Ice and Water In Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 34" x 48"
    Number of Awnings 1
    Axle Weight Front 13600 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 10000 lbs
    Water Heater Type Aqua Hot 400D
    AC BTU 45000 btu
    Basement Storage 152 cu. ft.
    TV Info LR LED TV, Cab LED TV, BR LED TV, Ext. LED TV
    Awning Info 18' Power w/LED Lighting & Motion Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 58600 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

Discovery LXE Features:

Standard Features (2024)



Chassis Components

  • Power Assisted Steering
  • (2)12V Heavy Duty Chassis Batteries
  • BrakeSync (FCCC) (option)
  • Tire Pressure Monitoring System
  • Drive Tech Steering Wheel w/Optiview Instrument Cluster (FCCC)
  • Valve Stem Extensions
  • Front and Rear Aluminum Wheels
  • Steerable Tag (FCCC Ultra Steer) (only 44B, 44S)
  • Push Button Start (only 44B, 44S)
  • Tuned SACHS® Shocks
  • CSA Package - FCCC (option)

Construction

  • Steel Constructed Entry Step Box
  • Full Coverage Heavy Duty Undercoating
  • High Density Polystyrene Insulated Sidewalls, Roof and Floor
  • Quiet Insulated, Ducted A/C System
  • Vacu-Bond Aluminum Framed Constructed Sidewalls, Roof and Floors
  • Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
  • Full Pass Through Basement Storage w/Composite Floor and Wall Construction
  • Electric Slideout Systems
  • Painted Steel Frame Chassis Construction
  • Dryseal Edge Coating for all Ceilings, Walls and Floors
  • Powerlock System - Interlocking Floor, Walls and Roof
  • Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot Operational)

Exterior

  • Fiberglass Wheel Well Skirts
  • Basement Pass-Through Storage
  • Front, Side and Rear Clearance and Marker Lighting
  • Porch Light w/Interior Switch
  • Automatic Hydraulic Leveling Jacks
  • Automatic Entrance Steps
  • Rear Ladder
  • 7-Way Round Tow Connection
  • Satellite Delete (option)
  • Fiberglass Rear Cap Assembly
  • Basement Storage LED Lighting
  • Unidirectional HD On-Air Antenna
  • Lighted Acrylic Grab Handle at Entry Door
  • Full Bay Slide Trays - 2nd Bay Single 90" (option) (N/A 36HQ)
  • Side Swing Aluminum Bus-Style Baggage Doors w/Locking Handles
  • Slideout Awning Toppers Above All Slideouts
  • Winegard In-Motion Satellite (option)
  • Exterior Freezer (option)
  • Patio Lighting
  • King Universal Stationary Satellite
  • Window Awning Package (option)
  • Fiberglass Front Cap Assembly
  • Powered Entrance Awning w/LED Lighting
  • Front and Rear Mud Flaps
  • Electric Patio Awning w/LED Lighting and Motion Sensor Retract
  • 4-Color Premier Full Body Paint
  • Roof Vent Rain Covers
  • Full Bay 90" Slide Tray
  • Oversized Dark Tinted Frameless Windows
  • Exterior Park Cable and Satellite Hookup
  • Entry Door w/Radiused Upper, Deadbolt and Screen Door
  • Molded-Fiberglass One-Piece Roof
  • Exterior Service Station - Includes: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hookup, Towel Holder and Drainage Valves
  • 2nd Roof Mounted Awning (option)
  • Front Cap Generator Access
  • Full Length Rearguard w/Nameplate
  • Undercarriage LED Lights
  • Rear Under Hood Utility Light

Cab Exterior

  • Top Mount Automotive Style Windshield Wiper System
  • Daytime Running Lights
  • Tinted Slider Driver Window
  • Automotive One Piece Windshield
  • Blind Spot Detection (option)
  • Front Mount, Remote Power/Heated Mirrors w/Turn Signals and Side Cameras
  • Lower Front Clear Protective Film
  • Fog Lamps

Interior

  • Power Motion Lounge w/Full Bed (44S)
  • Porcelain Tile Flooring
  • U-Shape Dinette (std. 40G, 44B) (option 44S)
  • Hardwood Cabinetry
  • Stackable Washer and Dryer (40G, 36HQ, 40M)
  • 120V/USB Receptacles
  • Loveseat w/Storage (36HQ, 40M)
  • Sofa w/Twin Sleeper Bed (36HQ)
  • Manual Day/Night Roller Shades
  • Electric Fireplace (Living Area) (40G, 40M, 44B)
  • Full Extension Drawer Guides w/Latches
  • Sofa w/Queen Sleeper Bed & Ottoman(s) (44B)
  • Side-By-Side Washer and Dryer (44B, 44S)
  • Energy Efficient LED 3" Flush Mount Ceiling Lighting
  • Free Standing Dinette w/Credenza (std. 40M, 44S) (option 44B)
  • Coordinating Window Treatments
  • Sofa w/Storage (only 44B)
  • Facing Dinette Booth (option only avail. for 40M, 44B)
  • Adapt-table® Dinette (only 36HQ)
  • Hidden Hinge Cabinet Doors
  • Sofa w/Full Sleeper Bed (only 40G, 40M)
  • Hardwood Ceiling Feature Trim w/Lighting
  • Dual Recliners (option only avail. for 44B)
  • Power Motion Lounge (option) (N/A 44S)
  • Floor Heat (Living Area)
  • Floor Heat (Rear) (option)
  • Interior Soft Touch Vinyl Ceiling

Interior Entry

  • Entry Door Manual Roller Shade and Blind
  • Power Entry Step Cover
  • Solid Surface Entry Step w/LED Accent Lighting
  • Battery Disconnect Switch at Entry Console
  • Metal Interior Grab Handle

Electric and Utilities

  • Water Accumulation System
  • CO and Smoke Detectors, Fire Extinguisher
  • Batteries:(6) 6V Deep Cycle House Batteries
  • High Capacity Water Pump
  • Multiplex Wiring System
  • Generator: 8000W Onan Quiet Diesel
  • Sensored Tank Monitoring through Multiplex
  • Energy Management System (EMS)
  • Water Filtration System (Whole Coach)
  • Inverter: Single 2000W Pure Sine w/Remote
  • Air Conditioners:(3)15,000 BTU Roof Mount, Ducted w/Chill Grill and Rear Heat Pump
  • Generator Auto Changeover
  • A/Cs w/Condensation Pump (option)
  • Aqua-Hot 400D
  • Transfer Switch w/Surge and Reverse Polarity Protection
  • Electric Power Cord Reel
  • Cable TV/Satellite Hookup
  • Neutral Loss Protection
  • Service Panel: 50 Amp,120 Volt
  • 100W Solar Panel
  • Black Holding Tank San-T-Flush System
  • Auto Gen Start
  • Electric Water Hose Reel
  • Dual Gravity Water Fill
  • Power Converter: 60 Amp
  • Safe-T-View Camera System
  • Central Vacuum System

Kitchen

  • Stainless Steel Farmhouse Sink
  • Full Extension Drawer Guides w/Latches
  • Adjustable Shelving
  • Polished Solid Surface Sink Covers
  • Polished Solid Surface Galley Countertop
  • Glass Tile Backsplash
  • 2-Burner Induction Cooktop
  • Waste Basket
  • Stainless Steel OTR Convection Microwave
  • Pantry Storage
  • Dishwasher
  • Stainless Steel Residential Refrigerator
  • Power Vent
  • Shadow Box Glass Tile Backsplash w/Window and Shade (N/A 40G)
  • Residential Faucet w/Pullout Sprayer

Bedroom/Bunk

  • Individual Reading Lights at Bed Overhead
  • Encore Series King Bed
  • Spacious Wardrobe Storage w/Hardwood Doors
  • 120V/USB Receptacles at Nightstands
  • 28" x 73" Bunk Beds w/4" Foam Mattress (40G, 44B)
  • Designer Bedspread and Pillows w/Shams
  • Headboard
  • Solid Surface Bedroom Countertops
  • Remote Generator Start Switch

Bathroom

  • Designer Shower Head Assembly
  • Medicine Cabinet w/Mirror
  • Towel Ring(s) and Toilet Paper Holder
  • Porcelain Toilet w/Macerator
  • Power Vent(s)
  • Residential Sink(s)
  • Glass Shower Door
  • Tile Backsplash
  • Tile Shower
  • Accent Lighting
  • Residential Faucet(s)
  • Shower Skylight
  • Polished Solid Surface Countertop(s)

Entertainment

  • Exterior Entertainment Center w/LED TV and Bluetooth® Soundbar
  • LED TV(Living Area) (40G, 36HQ, 44S)
  • Mid Wall LED TV(Living Area) (option only avail. for 40M)
  • Soundbar TV Sound System (Living Area)
  • LED TV(Front Overhead)
  • Pop-up LED TV(Living Area) (40M, 44B)
  • LED TV(Bedroom)

Cab Interior

  • Color Backup Monitor
  • Driver Console w/Lower Storage Bin
  • Driver and Passenger Overhead Storage Cabinetry
  • 12Vand USB Accessory Ports
  • LED Optiview Instrument Panel
  • Hide-A-Loft™ Power Drop-Down Overhead Bunk w/LED TV (option)
  • Momentary Battery Booster Switch - Connecting Chassis and House Batteries
  • Electronic Cruise Control
  • Driver and Passenger Side Manual Roller Shades and Blinds
  • 10.2" Stereo w/Touch Screen w/AM/FM/CD/DVD/Bluetooth/Navigation/APP Store/WiFi
  • Front Power Roller Blind
  • Switch for Exterior Service Lights
  • Air Suspension Deflation System (w/Tag Dump Switch on 44' Floor Plans) (40G, 36HQ, 40M)
  • Sirius/XM Satellite Radio Ready (Requires Subscription)
  • Dash Air Conditioning and Heat
  • Automatic Leveling Jacks Touchpad Controls
  • Seat Belts - 3 Point Driver and Passenger
  • Passenger Console
  • Adjustable Suspended Pedals
  • Radio Switch Main/Auxiliary Power at Dash
  • Power Locks w/Key FOB Control
  • Electric Alert Horn
  • Switch for Power/Heated Mirrors
  • Windshield Wipers w/Delay
  • Automotive StyleWrap Around Dash
  • Passenger Seat w/Reclining Back, Swivel, 6-way Power Controls, Heat and Power Footrest
  • 120VAC Outlet at Dash and Passenger Area
  • Driver Seat w/Reclining Back, Swivel, 6-way Power Controls, Heat
  • Keyless Entry w/Remotes

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.

Manu-Facts:

Fleetwood is one of the oldest names in the RV industry. We’ve been around for over 65 years—more than double most of our competition. And that resilience speaks to our product. After all, a company can’t stay in business if they build something people don’t believe in.



Inherently motorhomes are just that—a little bit vehicle, a little bit house. So at Fleetwood, we engineer and build them with both in mind. Our innovation shows we perfectly balance and blend the two. And that smarter design means a better RV.
